YT DECOY MX CORE 1 Bosch CX Gen5 800Wh Midnight White

YT DECOY CORE 1 — Entry-Level, Fully Loaded

The CORE 1 redefines what an entry-level eMTB can be. Featuring the same carbon frame, Bosch Smart System, and 180/170mm travel as its higher-end siblings, this build is anything but basic. Marzocchi’s Bomber Z fork and Bomber Air shock deliver plush, easy-to-tune suspension. Shimano Deore 12-speed shifting, WTB alloy wheels, and SRAM DB8 brakes provide solid performance for new riders or budget-conscious thrill seekers. It’s the perfect gateway to the DECOY family — capable, confidence-inspiring, and ready to rip.

Decoy Core 1 — Specifications

• Frame:
  Ultra Modulus Carbon Frame V4L | 170 mm rear travel | 148x12 mm YT Thru Axle

• Fork:
  Marzocchi Bomber Z 29" | 180 mm travel | 110 x 15 mm | 44 mm offset | White

• Shock:
  Marzocchi Bomber Air | 230 x 65 mm | Custom Tune

• Drive Unit:
  Bosch Performance Line CX | 85 Nm | 600 W Peak Power (unlockable via app to 100 Nm / 750 W)

• Battery:
  Bosch PowerTube 800 | Integrated | 800 Wh | 36 V | 4A Charger

• Controller:
  Bosch Kiox 400C | USB-C | ANT+ | Bluetooth | Flow App | Navigation

• Headset:
  ACROS AZA-1370 / 1113-BL ZS56 ZS56 | Block Lock 150° (Size S only) | Custom High Cap | 2 x 5 mm Spacers

• Stem:
  YT Stem 35 | 40 mm | +/-6° | Custom Black

• Handlebar:
  YT Handlebar 35 | 800 mm width | 7° Back | 5° Up | 40 mm Rise | Custom Black

• Grips:
  ODI Elite Motion V2.1 Lock-On

• Crankset:
  ethirteen Helix Core espec BOSCH | 160 mm | Black

• Chainring:
  ethirteen Helix Core espec | 36T | Direct Mount | Black

• Chainguide:
  ethirteen Core espec BOSCH CX Gen 5 | 32–36T compatible

• Cassette:
  Shimano Deore M6100 | 10-51T | 12-Speed

• Derailleur:
  Shimano Deore M6100 | 12-Speed

• Shifter (Rear):
  Shimano Deore M6100 | SL-M6100-IR

• Wheelset:
  WTB Sportterra Tough

  • Front: 29" | 30 mm internal width | 110 x 15 mm | 6-Bolt

  • Rear: 27.5" | 30 mm internal width | 148 x 12 mm | 6-Bolt | MicroSpline (MS)

• Tires:

  • Front: Continental Kryptotal-Fr | 29” x 2.4 WT | Super Soft | Enduro

  • Rear: Continental Kryptotal-Re | 27.5” x 2.4 WT | Soft | Enduro

• Brakes:
  SRAM DB8 Stealth | Maxima Mineral Oil

  • Rotors: SRAM Centerline 220 mm (front) / 200 mm (rear)

• Seatpost:
  YT Seatpost w/ Shimano SL-MT500-IL Remote

  • Drop:

    • 150 mm (S)

    • 170 mm (M)

    • 200 mm (L–XXL)

  • Diameter: 34.9 mm

• Saddle:
  YT Saddle | 144 mm width | Steel Rails | YT Custom Design

• Colour Options:
  Midnight White

• Sizes Available:
  S / M / L / XL / XXL

• Weight:
  Not specified (others in range are around 23–24 kg)

Bosch Smart System Specs

• Drive Unit: Bosch Performance CX (85 Nm, 600W peak, unlock to 100Nm / 750W)

• Battery: Bosch PowerTube 800 (800Wh)

• Display/Controller: Bosch Kiox 400C w/ USB-C, Flow app, Bluetooth, ANT+, navigation

The ALL NEW DECOY MX Geometry

Measurements: millimeters (mm)
Flip Chip position: Regular (Head Angle is 63.5 in the LOW position)

Frame size, guideline for best fit
• S: 154 cm - 165 cm // 5'1" - 5'5"
• M: 163 cm - 175 cm // 5'3.5" - 5'9"
• L: 173 cm - 184 cm // 5'8" - 6'0.5"
• XL: 182 cm - 193 cm // 6'0" - 6'4"
• XXL: 193 cm - 202 cm // 6'3.3" - 6'7.5"

Kinematics Snapshot

• Pedal Kickback (36T / 10-51T): Starts around 23° and drops to ~2° as travel increases

• Anti-Squat: Starts ~135% at sag, decreasing steadily with travel

• Anti-Rise: Consistent ~65–80%

• Leverage Ratio: Progressive, starting ~3.3 and descending to ~2.1 through 160 mm travel

In a nutshell: The YT Decoy CORE 1 is a full-carbon, Bosch-powered electric mountain bike with long-travel Marzocchi suspension, Shimano Deore 12-speed drivetrain, and SRAM brakes — all at an unbeatable price point. Built for new riders, weekend adventurers, and eMTB newcomers who want real performance without the premium price tag.

Tech Highlights: Bosch Performance Line CX | 800Wh Powertube Battery | Marzocchi Bomber Suspension | Shimano Deore 12-Speed | SRAM DB8 | WTB Wheels | Enduro e-MTB | Full Carbon Frame

FAQs

• What terrain is the CORE 1 designed for?
  The CORE 1 is ideal for trail, enduro, and bike park riding thanks to 180/170mm of travel and Bosch power.

• Is the battery removable for charging?
  Yes, the Bosch Powertube battery although fully integrated is removable with tools.

• Is Marzocchi suspension good?
  Yes, Marzocchi suspension is a real performer. Marzocchi is owned and manufactured by FOX suspension.
